Description:

When the best demand the best, it’s time for the toughest and most powerful: the Scag® Industrial Tow-Behind Truck Loader. No matter the job—from landscaping and municipal operations to golf courses—this machine features the commercial-grade size and performance needed to get the job done. Leave the rest behind and work with the best.

Fabricated and Balanced, 25-Inch, 4-Blade Impeller

Within the unit’s 10.5″-wide housing is a welded-steel impeller with 1/2″-thick steel blades. Dynamically balanced for reduced vibration, longer life and less stress on the engine, these loaders boast an effective, high-output (35BV = up to 6,781 CFM; 37CH = up to 6,909 CFM; 49KBD = up to 7,318 CFM), debris-reducing design.

Specification:

TLB25-35BV

• Engine: Briggs & Stratton® Vanguard™ BIG BLOCK™, V-Twin, electric start
• HP: 35
• Fuel Capacity / Tank: 8.5 gallons – plastic tank with built-in fuel gauge
• CFM Output: 6,781
• Frame Construction: All-steel, welded
• Impeller Construction: 4-blade, 1/2″-thick blades, all-steel, welded
• Impeller Mounting: Straight bore
• Impeller Diameter / Width: 25″ / 9″
• Blower Housing Construction: Removable back panel for easy impeller and wear plate access
• Blower Housing Width: 10.5″
• Blower Housing Wear Plates: Standard: 1/4″-steel, replaceable
• Intake Hose Specifications: 84″ length, 16″-diameter intake hose, 0.045 blue polyurethane rubber, wire helix with wearstrip
• Unit Mounting: Hitch: at least 10,000 lb rating
• Discharge Tube: Clear thermoplastic, 12″ diameter, 84″ length
• Throttle Control: Commercial-grade, all-steel mechanicals
• Highway Ready: Yes – standard roadside package, including wheel chocks and cones
• Axle: Heavy-duty Dexter Torflex® axle (3,500 lb)
• Tires: 205 / 75 D15 highway tires with steel wheels
• Trailer Width: 66.75″
• Accessories: Light Kit, Brake Kit
• Height: 121.25″
• Weight: 1,700 lb
• Warranty: 2-Year Commercial; 90-Day Rental
• MSRP: $16,249

Description:

Welded and fabricated using military-grade steel for years of dependable performance, the SFC-30 Finish Cut Walk-Behind Mower is no pushover. Packing big productivity and versatility into a compact form, this commercial-grade machine delivers a beautiful, professional quality-of-cut, helping you put the finishing touches on the job or at home.

Features:

Mow with Ease

• Front Swivel Caster Wheels: Enhance maneuverability in landscaped areas with front swivel caster wheels. Convert fixed wheel models to swivel with an available accessory.

Fully Fabricated and Welded Steel Cutter Deck

• Military-Grade Steel Deck: Constructed with a 14-gauge, grade 100 Military-Grade steel deck shell, 12-gauge spindle reinforcement plate, and ¼” side reinforcement bar for unmatched durability and a quality cut.

Fully Fabricated and Welded Steel Frame

• Military-Grade Steel Frame: The steel frame is over 200% stronger than standard drawing steel used in common stamped frames and decks, providing superior strength and longevity.

Single Point Height-of-Cut Adjustment

• Fine-Tuned and Simple: Easily adjust the cutting height from a single location, with settings from 1.5” to 5” in .25” increments, eliminating the need for multiple adjustments.

Offset Blade Setup

• Simplified Deck Drive System: Features a less complex, easier-to-maintain offset blade design compared to traditional timed deck setups. Reduces repair/replace time for belts.

Scag Level Quality-of-Cut

• Unmatched Performance: Large cutting chamber processes more grass and efficiently handles wet and lush springtime grasses. Oversized discharge opening for superior performance.

Operator Control Panel

• Ergonomic Controls: Controls are designed to match the natural angles of your hands, making them easily accessible. Includes blade brake engagement, drive engagement, recoil start, throttle/choke, hour meter, and park brake.

Oversized Adjustable Controls

• Achieve Maximum Comfort: Oversized handles with internally routed cables for protection and tool-free height adjustment for operator comfort. Includes vertical adjustment for transportation or storage.

Discharge – Mulch – Bag

• 3-in-1 Versatility: Offers discharge, mulch, or bag options. Standard equipment includes discharge chute, deck plug and mulch plate, bagging baffle, and fabric bag for flexible operation.

Powerful Transmission & Engine Combo

• Maximum Power for Tough Cuts: Combines the GT MV702 transmission with the Kohler CV224 engine for optimal performance in demanding cutting conditions.

Specification:

• Description: 30″ fully fabricated steel cutter deck, Kohler 224CV engine – recoil-start engine
• Horsepower: 7

Product Dimensions

• Length – Transport (handles in upright transport position): 41″
• Length – Minimum (handles in highest operating position): 66″
• Length – Max (handles in lowest operating position): 73.5″
• Tracking Width: 28.75″
• Width (w/ discharge chute): 36.75″
• Width (w/ discharge block off plate): 31.5″
• Height – Lowest Operating: 36.75″
• Height – Max Operating: 45.25″
• Height – w/ Handle Bar in Storage Position: 57.5″
• Operating Weight – Bagging: 220 lbs.
• Operating Weight – Mulching: 214 lbs.
• Operating Weight – Discharging: 213 lbs.

General Specifications

• Total Fuel Capacity: 1 gallon (0.37 gallon capacity for California models)
• Rear Tires: 10.5″ x 3″ rubber tire with glass-filled polypropylene wheel
• Front Tires: 9” x 2.25” rubber tire with glass-filled polypropylene wheel
• Drive System Type: GT MV 702 Transmission
• Forward Ground Speed: Up to 4 mph
• Parking Brake: Hand lever

Deck Specifications

• Cutting Width: 30″
• Type: Extra-strong, fully fabricated and welded steel cutter deck. Offset blade, non-timed deck setup.
• Cutting Height: 1.5″ to 5″ in .25″ increments
• Blade Type: Optimized for maximum performance whether discharging, mulching, or bagging
• Deck Lift: Hand lever, single-point adjustment
• Construction: 14-gauge, grade 100 Military-Grade steel deck shell with 12-gauge spindle reinforcement plate, ¼” trim side reinforcement bar for extra protection against impacts
• Spindles: Aluminum housing with sealed ball bearings
• Blade Engagement: Blade brake clutch allows operator to disengage cutter blades without shutting off the machine
• Discharge, Mulch, Bag: Standard
• Bag Capacity: 2.5 Bushels

Description:

Because every home deserves stripes, the Liberty® Z is designed and manufactured to deliver a top-of-the-line experience at a homeowner price point. A professionally-constructed mower, fit for your own lawn. The Liberty Z gives more people the chance to see why Scag® machines are Simply the Best.

Other manufacturers opt for less expensive, smaller-capacity, nonadjustable, “disposable” clutches. Not Scag®. Scag PTO clutch brakes are manufactured by Ogura, the world’s best manufacturer of electromagnetic clutches, providing smooth blade engagements and fast blade stops.

All Ogura clutches feature an adjustable air gap. What does that mean to you? It means that when most clutches are worn out and must be replaced at a significant cost to YOU, the Ogura clutch can be easily adjusted to bring it back into specification (your Scag dealer can perform this adjustment).

These clutches also feature industry-leading torque values (the holding power that links the engine to the cutter-deck drive system) to ensure solid drive to the cutter deck and no slipping in heavy conditions.

Features:

Ogura PTO Clutch Brake

• Strong, Adjustable Clutch for Long Life: The Ogura GT1 PTO Clutch Brake provides excellent starting and stopping power for the cutter deck with 74 ft. lb. of holding strength. It features an adjustable air gap for increased durability and longevity.

Deep, Fabricated, and Welded Cutter Decks

• Heavy-Duty Hero Cutter Deck: Designed for superior quality-of-cut, the deep, fabricated deck handles large volumes of grass at high speeds. Heavy-duty aluminum, sealed ball bearing blade-drive spindles ensure reliable performance season after season.

High-Strength Steel Frame

• Solid Design for Years of Dependable Service: The tubular-steel main frame offers unmatched strength and durability for long-term use.

Low-Maintenance Mower Design

• More Uptime: Reduced grease points for increased operator convenience and ease of ownership, minimizing maintenance needs.

Proven Transaxles

• Speeds Up To 7 MPH: The Liberty Z features proven dual hydro transaxles (Tuff Torq TZ450, Hydro-Gear ZT-2800, or ZT-3100, depending on the model) for smooth and solid power delivery to the drive wheels.

Contoured, Bolstered, High-Back Seat

• Ride in Comfort: Ultra-comfortable, adjustable seat (with tools) featuring armrests* for improved comfort. *Armrests are standard on 48″, 52″, and 61″ models; optional for 36″ and 42″ models.

Easy Foot-Pedal Deck Lift

• Easy Up, Easy Down: Spring-assisted foot-pedal cutter-deck lift makes raising and lowering the cutter deck smooth and effortless.

Powerful and Efficient Engine Options

• Reliable Power, Up To 27 HP: A range of proven air-cooled, V-twin engine options available to meet various performance needs.

Specification:

• Description: 42″ Hero Cutter Deck, 22 HP Kohler® 7000 Series™ PRO – 725 cc displacement

Product Dimensions

• Length: 68.5″
• Width (chute down): 54.5″
• Width (chute in transport position): 43″
• Height: 41″
• Weight: 595 lb

General Specifications

• Total Fuel Capacity: 5.5 gallons
• Drive Tires: 20″ x 10″-8″
• Caster Tires: 11″ x 6″-5″
• Seat: Padded with armrests, forward and back adjustment (tools required)
• Drive System Type: Tuff Torq TZ450 Transaxle
• Pumps: Internal Pump: 10 cc
• Motors: Internal Motor: 10cc (Tuff Torq), 16 cc (Hydro-Gear)
• Forward Ground Speed: 7 mph
• Reverse Ground Speed: 5 mph
• Parking Brake: Hand lever

Deck Specifications

• Cutting Width: 42″
• Type: Heavy-Duty Hero Cutter Deck
• Cutting Height: 1.5″ to 4.5″ in .25″ increments
• Deck Lift: Foot-operated pedal
• Construction: Dual-plate cutter deck constructed of 2 steel plates with a reinforcement plate at cutter deck spindles
• Spindles: Aluminum housing with sealed ball bearings
• Blade Engagement:
• Ogura GT1 (74 ft-lb) for 36″, 42″, 48″, and 52″ models
• Ogura GT2 (108 ft-lb) for 61″ models
• Adjustable air-gap for extended life

Description:

48" Velocity Plus™ Cutter Deck, 23 HP Kohler® Command PRO®

Features:

• The envy of the neighborhood - 48", 52" or 61" Cutting Width: The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge on 48", 52" and 61" widths. An Advantage Cutter Deck is featured on 32" and 36" widths.
• Adjustable Operator Platform - Experience an Unmatched, Ultra-Comfortable Ride: The spacious operator platform delivers a smooth ride and reduces operator fatigue. Adjustable suspension spring can be moved forward or backward, with, or without, the spacer plate installed to meet the operator's comfort preference. Extra-large, extra-thick operator comfort cushion ensures comfortable operation, hour after hour.
• Cutter-Deck Lift System - Convenient, Spring-Assisted Lever: Cutter deck can be lifted and locked into transport position from the operator's station. Cutting heights are easily set by placing the tethered pin at the desired height.
• Ogura PTO Clutch Brake - Strong, Adjustable Clutch for Long Life: Provides excellent starting and stopping power for the cutter deck and an adjustable air gap for long life.
• Ease of Maintenance - More Uptime: Easy-to-remove covers, an unrestricted engine compartment, easy-to-reach grease Zerks and many more features make servicing the V-Ride™ II simple, so you can be in the shop less and on the job more.
• High-Strength Steel Frame - Solid Design for Years of Dependable Service: Heavy-duty, single-tube, steel main-frame construction delivers superior strength and ensures years of trouble-free service. The front caster-wheel weldments are replaceable.
• Powerful and Efficient Engine Options - Huge Power, Up To 40 HP: Choose from Briggs Vanguard and Kawasaki® powerplants; electronic fuel injection (EFI) options are available.
• Tiger Eye Advanced Monitoring System - Keep a Real-Time "Eye" on Important System Functions: Depending on the mower model and engine selection, the Tiger Eye™ Advanced Monitoring System monitors a wide variety of systems in real-time, giving you valuable information in just a glance, right from the operator's seat. (Tiger Eye not available on 32" and 36" V-Ride II models.)
• Industrial-Grade Hydraulic System - Speeds Up To 10.5 MPH: 48", 52" and 61" models: Dual Hydro-Gear pumps (12 cc) and Parker wheel motors (14 ci) deliver dependable power, with speeds up to 10.5 mph. Pump shock valves ensure reliability and long life. Cooling fans help maintain safe operating temperatures. 32" and 36" models: Dual Hydro-Gear pumps (10 cc) and Parker wheel motors (12 ci) deliver dependable power, with speeds up to 8.5 mph.

Specifications:

• Description: 48" Velocity Plus™ Cutter Deck, 23 HP Kohler® Command PRO®
• Total Fuel Capacity: 5 gallons (32"); 6.75 gallons (36"); 8 gallons (48", 52", and 61")
• Drive Tires: 20" x 6.5"-10" (32"); 20" x 8"-10" (36"); 24" x 9.5"-12" (48" and 52"); 24" x 12"-12" (61")
• Caster Tires: 11" x 4"-5" (32" and 36"); 13" x 5"-6" (48" and 52"); 13" x 6.5"-6" (61")
• Seat: Extra-large comfort cushion
• Drive System Type: Dual Pump and Motor
• Pumps: Hydro-Gear 10 cc (32" and 36"); Hydro-Gear 12 cc (48", 52", and 61")
• Motors: Parker 12 ci (32" and 36"); Parker 14 ci (48", 52" and 61")
• Forward Ground Speed: 8.5 mph (32" and 36"); 10.5 mph (48", 52" and 61")
• Reverse Ground Speed: 5 mph
• Parking Brake: Hand lever
• Cutting Widths: 32", 36", 48", 52" and 61"
• Type: Advantage (32" and 36"); Velocity Plus™ (48", 52", and 61")
• Cutting Height: 1.5" to 4.5" in .25" increments
• Deck Lift: Hand lever
• Construction: Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2" of steel. Reinforcement plates at cutter deck spindles.; 32" model features dual-plate.
• Spindles: Cast-iron housing with tapered roller bearings.
• Blade Engagement: Ogura GT2.5 (150 ft lb) - (32", 36", 48" and 52"); Ogura GT3.5 (250 ft lb) - (61"); Adjustable air-gap for extended life.

Dimensions

• Length: 67.5"
• Tracking Width: 48"
• Width (chute down): 61.25"
• Width (chute in transport position): 49.75"
• Height: 47.25"
• Weight: 1,015 lb

Accessories

• 2-Bag V-Ride II Spindle Driven Grass Catcher
• Fabric Bag Grass Catcher
• Hurricane Plus™ Mulch System
• Hurricane Mulch System
• Mulch Plate
• OCDC - Operator-Controlled Discharge Chute
• Light Kit
• Chrome Wheel Covers
• Air Filter Monitor
• Blade Buddy
• 12-Volt Accessory Outlet

Description:

Because every home deserves stripes, the Liberty® Z is designed and manufactured to deliver a top-of-the-line experience at a homeowner price point. A professionally-constructed mower, fit for your own lawn. The Liberty Z gives more people the chance to see why Scag® machines are Simply the Best.

Specifications:

• Deck Size: 52 inches
• Engine Power: 24 HP
• Engine Model: Kohler® 7000 Series™ PRO
• Displacement: 725 cc

Description:

All business—even at home—the Freedom Z® is perfect for landscapers needing a machine that can go the distance or for the pro-at-home who owns a large-acreage lot. Commercial-quality through and through, this machine is comfortable anywhere the job needs to be done.

Features:

• PTO Clutch Brake:
• Provides excellent starting and stopping power for the cutter deck.
• Offers 74 ft. lb. of holding strength.
• Adjustable air gap for enhanced durability.
• Cutter Deck:
• Deep, fabricated, and welded design for handling large amounts of grass at higher speeds.
• Heavy-duty Hero Cutter Deck construction for quality-of-cut.
• Aluminum, sealed ball bearing, blade-drive spindles for reliable performance.
• Frame:
• Tubular-steel main frame for unmatched strength and longevity.
• Transaxles:
• Hydro-Gear ZT-2800 Transaxles for speeds up to 8 MPH.
• Dual hydro transaxles with all-metal gears and spin-on oil filters.
• Large cooling fans to keep temperatures low and extend component life.
• Maintenance:
• Low-maintenance design with fewer grease points for increased operator convenience and uptime.
• Seat:
• Contoured, bolstered, high-back seat for improved comfort.
• Adjustable with tools and features armrests for added comfort during operation.
• Deck Lift:
• Easy foot-pedal deck lift with spring assistance for smooth raising and lowering of the cutter deck.
• Engine Options:
• Reliable power options up to 24 HP.
• Available with 22 hp and 24 hp Kohler® 7000 Series engines.
• PRO Performance filtration for smooth and consistent power delivery.

Specification:

• Engine: 26 HP Kohler® 7000 Series™ PRO – V-Twin, air-cooled engine.
• Cutter Deck: 52″ Hero Cutter Deck with dual-plate construction using 2 steel plates and a reinforcement plate at cutter deck spindles.
• Blade Engagement: Ogura GT1 PTO Clutch Brake with 74 ft lb holding strength and adjustable air-gap for extended life.
• Cutting Width: 52″
• Cutting Heights: Adjustable from 1.5″ to 4.5″ in 0.25″ increments.
• Deck Lift: Foot-operated pedal for easy adjustment.
• Drive System: Hydro-Gear ZT2800 Transaxle with internal pump (10 cc) and motor (16 cc).
• Speeds: Forward ground speed up to 8 mph, reverse ground speed up to 5 mph.
• Fuel Capacity: 6.5 gallons.
• Tires: Drive tires 20″ x 10″-10″, caster tires 11″ x 6″-5″.
• Seat: Padded with armrests, adjustable forward and back (tools required).
• Dimensions:
• Length: 73″
• Width (chute down): 64.5″
• Width (chute in transport position): 53″
• Height: 60″
• Weight: 765 lb

Description:

Featuring a comfortable operator platform with first-class suspension that minimizes fatigue, the V-Ride II™ delivers a natural, intuitive and smooth riding position the entire day. With unrivaled performance, stability and durability, this machine helps keep you in tip-top condition to get the job done day after day, year after year.

48", 52" or 61" Cutting Width

The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge on 48″, 52″ and 61″ widths. An Advantage Cutter Deck is featured on 32″ and 36″ widths

Scag® cutter decks have always given our competition a serious case of deck envy. Many try to duplicate the performance, but none can match it. The Velocity Plus™ cutter deck is an outstanding performer and delivers beautiful results.

The Velocity Plus™ Cutter Deck provides the unmatched power, precision and performance professionals demand. This revolutionary deck design delivers high-velocity discharge plus a beautiful manicured cut, even at faster ground speeds. A redesigned cutting chamber and massive discharge opening provide even greater cutting performance with maximum clipping dispersal in any conditions.

Strength — Scag’s tough cutter-blade spindles and Tri-Plate construction ensure solid performance and long life. A replaceable trim-side wear pad protects deck from damage.

Productivity — An extra-large discharge opening, paired with the Turbo Baffle, enhances discharge for even clipping dispersal.

Flexibility — The Velocity Plus cuts everything from fine grasses to tough weeds. The Custom-Cut™ Front Baffle System allows you to customize the deck to your individual conditions for even more productivity and higher performance.

Engines:

Kawasaki FT Series Engines

Commercial-Grade Power

The new Kawasaki® FT Series engines with patented Vortical air filtration blaze new trails.

Kawasaki® FT Series engines are designed and built to handle heavy loads. The Vortical air filtration system muscles out grass and debris while large, easy-to-access integrated clean-out ports amp up your efficiency and keep you cutting.

Other features include:

• 90° V-twin
• High-efficiency, centrifugal air intake system
• Dual-element air filtration with reinforced filter
• Large, easy-to-access integrated clean-out ports
• Pressurized lubrication system
• Electronic spark ignition
• Automatic compression release
• Internally vented carburetor with fuel shut-off solenoid
• Cast-iron cylinder liners

Specification:

• Specification - V-Ride II
• General:
• Total Fuel Capacity:
• 5 gallons (32″)
• 6.75 gallons (36″)
• 8 gallons (48″, 52″, and 61″)
• Drive Tires:
• 20″ x 6.5″-10″ (32″)
• 20″ x 8″-10″ (36″)
• 24″ x 9.5″-12″ (48″ and 52″)
• 24″ x 12″-12″ (61″)
• Caster Tires:
• 11″ x 4″-5″ (32″ and 36″)
• 13″ x 5″-6″ (48″ and 52″)
• 13″ x 6.5″-6″ (61″)
• Seat: Extra-large comfort cushion
• Drive System:
• Drive System Type: Dual Pump and Motor
• Pumps:
• Hydro-Gear 10 cc (32″ and 36″)
• Hydro-Gear 12 cc (48″, 52″, and 61″)
• Motors:
• Parker 12 ci (32″ and 36″)
• Parker 14 ci (48″, 52″ and 61″)
• Forward Ground Speed:
• 8.5 mph (32″ and 36″)
• 10.5 mph (48″, 52″ and 61″)
• Reverse Ground Speed: 5 mph
• Parking Brake: Hand lever
• Deck:
• Cutting Widths: 32″, 36″, 48″, 52″, and 61″
• Type:
• Advantage (32″ and 36″)
• Velocity Plus™ (48″, 52″, and 61″)
• Cutting Height: 1.5″ to 4.5″ in .25″ increments
• Deck Lift: Hand lever
• Construction: Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles. 32″ model features dual-plate.
• Spindles: Cast-iron housing with tapered roller bearings.
• Blade Engagement:
• Ogura GT2.5 (150 ft lb) – (32″, 36″, 48″, and 52″)
• Ogura GT3.5 (250 ft lb) – (61″)
• Adjustable air-gap for extended life.
• Length: 69.5″
• Tracking Width: 48″
• Width (Chute Down): 65.25″
• Width (Chute in Transport Position): 53.75″
• Height: 47.25″
• Weight: 1,000-1,022 lb

Description:

Built to deliver low-maintenance and high-performance operation, the Patriot™ makes a statement; it says you’re a hardworking lawn care professional that believes in getting a job done right. In other words, this machine is built to make money and leave your customers—and their neighbors—saluting your handiwork.

Specifications:

• Deck Size: 61 inches
• Engine Power: 27 HP
• Engine Model: Briggs CXi Series™

Description:

The Scag® SFC-21 Finish-Cut Walk-Behind mower is the compact machine you’ve always wanted—packing big productivity and versatility into a 21” wide platform. On the job or at home, the SFC-21 delivers a professional quality-of-cut that leaves behind a beautiful lawn, each and every time. Capable of 3-in-1 versatility (mulching, bagging and optional side discharging), it helps you tackle whatever challenges come your way with top-notch results.

EASY HEIGHT-OF-CUT ADJUSTMENT

FINE-TUNED AND SIMPLE

Easy height-of-cut adjustment allows for cutting heights from 1.5” to 4.5” in .5” increments.

Engines

Honda GXV160 Engine

Designed specifically to meet the demands of professionals working in commercial landscaping and other related industries, the Honda GXV160 delivers reliability and efficiency from dusk until dawn. Engineered with precision for smoother performance and quiet operation, this 4-stroke single cylinder engine features an OHV design for increased efficiency and optimal power transfer and is easy-to-start because of its automatic decompression system.

Features:

• Air-cooled, 4-stroke OHV 163 cc engine
• High power-to-displacement ratio
• High quality materials and purpose-built components ensure reliable long-term use
• Engineered for low vibration and quieter noise levels
• Easy starting with an automatic decompression system
• Large fuel tank and superior fuel efficiency for less downtime
• EPA certified

Specifications:

• Product Dimensions
• Length in Operating Position: 63.0 – 68.5 inches (both models)
• Length in Storage Position: 41 inches (both models)
• Tracking Width: 21.2 inches (both models)
• Width: 23.25 inches (both models)
• Height in Operating Position: 32.75 inches (low) / 43.5 inches (high)
• Height in Storage Position: 22 inches (both models)
• Weight (without bagger): 132 lb (SFC-21-5CV), 138 lb (SFC-21-7CV)
• Weight (with bagger): 137 lb (SFC-21-5CV), 143 lb (SFC-21-7CV)
• General Specifications
• General Type: Heavy-duty industrial/commercial (both models)
• Brand: Kohler® Command PRO® (both models)
• Model: CV173 (SFC-21-5CV), CV224 (SFC-21-7CV)
• Horsepower: 5HP @ 3300 RPM (SFC-21-5CV), 7HP @ 3300 RPM (SFC-21-7CV)
• Engine Type: 4-cycle gas, OHV, air-cooled, single-cylinder, vertical shaft (both models)
• Displacement: 173 cc (SFC-21-5CV), 224 cc (SFC-21-7CV)
• Cylinder: One with cast-iron cylinder bore (both models)
• Governor: Mechanical governor with variable speed control set at 3300 rpm, idle set at 1500 rpm (both models)
• Air Cleaner: Quad-Clean™ four-stage, cyclonic air filter (both models)
• Exhaust: Side discharge muffler with guard (SFC-21-5CV), Front discharge muffler with guard (SFC-21-7CV)
• Oil Pump Group: Steel oil pump; Full pressure lubrication with spin-on oil filter (both models)
• Starter/Electrical: Easy-Pull™ recoil start (both models)
• 50-State Compliant: Yes (both models)
• Engine Deck & Fuel Tank
• Engine Deck Thickness: 14 gauge (both models)
• Fuel Tank Capacity: 0.37 gallon (1.4 liters) plastic tank (SFC-21-5CV), 1 gallon (3.785 liters) plastic tank (SFC-21-7CV)
• Wheels & Tires
• Drive Tires: 10.5 x 3 (both models)
• Front Tires: 9 x 2.25 (both models)
• Handlebars & Drive System
• Handle Bars: 1" diameter, thick wall tubing, 3-position adjustable (both models)
• Transmission: GT MG 512 transmission, 3-speed (both models)
• Steering/Travel Control: Variable drive control bar and 3-speed selector lever on handlebar (both models)
• Transmission Output Shaft: 0.50" diameter (both models)
• Safety & Forward Speed
• Safety Group: Handle actuated operator presence system (both models)
• Forward Speed: Up to 4.25 mph (both models)
• Cutter Deck
• Cutter Deck Type: High-vacuum, high-capacity design (both models)
• Deck Construction: 14 gauge deck with 14-gauge replaceable guards for strength and longevity. Deep draw stamped (both models)
• True Cutting Width: 21 inches (53.34 cm) (both models)
• Cutting Height Adjustment: 1.5" to 4.5" in 0.5" increments (both models)
• Cutter Blade: 0.1345 in. thick, milled edge, wear-resistant (both models)
• Blade Engagement: Blade control bar controlled Blade Brake Clutch (BBC), connected to cutter blade (both models)
• Discharge Opening: Rear-discharge with extra wide discharge opening (both models)
• Clutch Type: Heavy-duty Blade Brake Clutch (BBC) (both models)
• Optional Items/Attachments
• Mulching Plug: Included (both models)
• Fabric Grass Catcher: Included; 2.2 bushels (2.74 cu. ft.) (both models)
• Side-Discharge Adapter: Available accessory (both models)

Description:

THE APEX PREDATOR:

It’s time for you to rise to the top of the food chain and tame turf with the Turf Tiger II™, a machine that’s tougher than any job you can throw at it. Engineered for superior durability, productivity and comfort, the Turf Tiger II gives you the edge over whatever nature throws at you while leaving you ready to take on the next challenge.

52", 61" or 72" Cutting Width:

The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge. This deck is equipped with Scag’s ultra-tough cast-iron spindles featuring tapered roller bearings and a top-mounted grease fitting with a relief valve to prevent over-greasing.

Features:

Scag® cutter decks have always given our competition a serious case of deck envy. Many try to duplicate the performance, but none can match it. The Velocity Plus™ cutter deck is an outstanding performer and delivers beautiful results.

The Velocity Plus™ Cutter Deck provides the unmatched power, precision and performance professionals demand. This revolutionary deck design delivers high-velocity discharge plus a beautiful manicured cut, even at faster ground speeds. A redesigned cutting chamber and massive discharge opening provide even greater cutting performance with maximum clipping dispersal in any conditions.

• Strength — Scag’s tough cutter-blade spindles and Tri-Plate construction ensure solid performance and long life. A replaceable trim-side wear pad protects deck from damage.
• Productivity — An extra-large discharge opening, paired with the Turbo Baffle, enhances discharge for even clipping dispersal.
• Flexibility — The Velocity Plus cuts everything from fine grasses to tough weeds. The Custom-Cut™ Front Baffle System allows you to customize the deck to your individual conditions for even more productivity and higher performance.

Engines:

Kohler Command PRO EFI Engines

Experience tremendous power, productivity and fuel savings with this winning combination of engine and machine. With its closed-loop injection system and heavy-duty air-filtration system, the EFI engine delivers superior performance, custom-made for the most demanding conditions.

This engine offers optimal fuel efficiency, consistent running temperatures and quiet operation. Easy-to-access service points, a solenoid shift starter and a 3-year limited warranty* put the finishing touches on this impressive package.

Other features include:

• Closed-loop electronic fuel injection for maximum fuel efficiency.
• Aluminum block with cast-iron cylinder liners.
• Industrial-grade air-filtration system ensures maximum protection of interior engine components.
• Dual air filters deliver maximum performance. The main filter traps dirt and debris while the inner filter prevents carburetor contamination during main filter servicing.
• Overhead valve design produces more power, improves fuel economy and cooling, and reduces oil consumption.
• Full-pressure oil-lubrication system with spin-on oil filter.
• Various user-friendly features: dual oil drains, easy-access oil fill, in-line fuel filter.
• Commercial-grade solenoid shift starter means quick, reliable starts.

Specifications:

Product Dimensions

• Length: 80.5"
• Width (Chute Down): 64.5"
• Width (Chute in Transport Position): 53.75"
• Height (ROPS Down): 46.5"
• Height (ROPS Up): 68"
• Weight: 1,418 lbs

General Specifications

• Total Fuel Capacity:
• Gas/Diesel: 12 gallons
• LP: 33.5 lbs
• Drive Tires: 26" x 9.5"-12"
• Caster Tires: 13" x 6.5"-6"
• Seat: 4-point iso-mounted torsion-spring suspension seat

Drive System

• Drive System Type: Dual Pump and Motor
• Pumps: Hydro-Gear: 16 cc
• Motors: Parker: 18 ci
• Forward Ground Speed: 12 mph (Gas/LP), 10 mph (Diesel)
• Reverse Ground Speed: 6 mph
• Parking Brake: Adjustable foot-operated pedal, AUSCO disc brakes

Deck Specifications

• Cutting Width: 52"
• Cutting Type: Velocity Plus™
• Cutting Height: 1.5" to 6" in 0.25" increments
• Deck Lift: Adjustable foot-operated pedal
• Deck Construction: Tri-plate cutter deck with 3 steel plates totaling nearly 1/2" thickness, reinforcement plates at cutter deck spindles
• Spindles: Cast-iron housing with tapered roller bearings
• Blade Engagement: Ogura GT3.5 (300 ft-lb)
• Ogura GT5 (350 ft-lb) for Briggs Models
• Adjustable air-gap for extended life

Description:

With incredible ground-clearing force, nothing gets in the way of the Extreme Pro Blower and its massive air output of up to 2,824 CFM. Heavy-duty construction ensures years of dependable service and worry-free performance, and its 17″ steel, 6-blade impeller is dynamically balanced for smooth operation.

Specifications:

Engine

• Type: Honda GX390
• Horsepower: 11.7 HP

Performance

• Total Fuel Capacity: 1.61 Gallons
• CFM Output: 2,824

Design and Construction

• Frame: All-steel, welded, 10-gauge
• Impeller: All-steel, welded, 6-blade, dynamically balanced
• Impeller Mounting: Tapered locking hub
• Impeller Diameter/Width: 17″ / 4.25″
• Blower Housing: All-steel, welded, 10-gauge front and back housing plates; 12-gauge skirt
• Blower Housing Width: 6″
• Blower Tilt Angle: 2-degree tilt at discharge

Handle and Controls

• Handlebar: Tubular steel with thick, comfortable foam grip; 3-position, adjustable height
• Vibration Control: 8-point iso-mount handlebar

Discharge and Wheels

• Discharge Opening: 26.25 square inches
• Discharge Control: Quick-lever located near discharge
• Discharge Angle Control: Yes – mechanical lever
• Axle: 3/4″-diameter steel
• Front Wheels: 4.10″ x 3.5″ pneumatic tire
• Rear Wheels: 13″ x 5″-6″ pneumatic Turf Sale tires

Dimensions and Weight

• Length: 52″
• Width: 30.25″
• Height: 42.5”, 43.75″, 45”
• Weight: 190 lb

Warranty

• Commercial Warranty: 2 Years
• Non-Commercial Warranty: 2 Years
• Rental Warranty: 90 Days

Description:

In your world, it pays to become more swift, agile and powerful. Make it a reality with the quick and precise Cheetah II™, a machine that devours jobs at a pace you’ve only dreamed of while delivering an unmatched quality-of-cut and incredibly smooth ride. With the Cheetah II, you’ll never be caught from behind.

61" OR 72" CUTTING WIDTH

The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge. This deck is equipped with Scag’s ultra-tough cast-iron spindles featuring tapered roller bearings and a top-mounted grease fitting with a relief valve to prevent over-greasing.

Specification:

pecifications for Scag Cheetah II Models:

- Model: 61″ Cheetah

 - Length: 87″-91.25″

 - Width (chute down): 73.5″

 - Width (chute in transport position): 62.75″

 - Height (ROPS folded): 49.5″

 - Height (ROPS up): 67″

 - Weight: 1,364-1,392 lb

- Model: 72″ Cheetah

 - Length: 91″-97.5″

 - Width (chute down): 83″

 - Width (chute in transport position): 73″

 - Height (ROPS folded): 49.5″

 - Height (ROPS up): 67″

 - Weight: 1,399-1,427 lb

Blackout Edition:

- Available Models: SCZII-61V-38CV-EFI, SCZII-72V-38CV-EFI

- Exclusivity: Currently exclusive to these models, subject to store availability.

- Special Features: Unique design and specifications.

- Note: Seat style and design may vary.

Description:

In your world, it pays to become more swift, agile and powerful. Make it a reality with the quick and precise Cheetah II™, a machine that devours jobs at a pace you’ve only dreamed of while delivering an unmatched quality-of-cut and incredibly smooth ride. With the Cheetah II, you’ll never be caught from behind.

Specifications:

Cutting Deck

• Type: Velocity Plus™
• Cutting Width: 61 inches

Engine

• Brand: Kohler
• Model: Command PRO® EFI
• Horsepower: 38 HP
• Fuel System: Electronic Fuel Injection (EFI)

Description:

The Scag® SFC-21 Finish-Cut Walk-Behind mower is the compact machine you’ve always wanted—packing big productivity and versatility into a 21” wide platform. On the job or at home, the SFC-21 delivers a professional quality-of-cut that leaves behind a beautiful lawn, each and every time. Capable of 3-in-1 versatility (mulching, bagging and optional side discharging), it helps you tackle whatever challenges come your way with top-notch results.

EASY HEIGHT-OF-CUT ADJUSTMENT

FINE-TUNED AND SIMPLE

Easy height-of-cut adjustment allows for cutting heights from 1.5” to 4.5” in .5” increments.

Engines

Honda GXV160 Engine

Designed specifically to meet the demands of professionals working in commercial landscaping and other related industries, the Honda GXV160 delivers reliability and efficiency from dusk until dawn. Engineered with precision for smoother performance and quiet operation, this 4-stroke single cylinder engine features an OHV design for increased efficiency and optimal power transfer and is easy-to-start because of its automatic decompression system.

Features:

• Air-cooled, 4-stroke OHV 163 cc engine
• High power-to-displacement ratio
• High quality materials and purpose-built components ensure reliable long-term use
• Engineered for low vibration and quieter noise levels
• Easy starting with an automatic decompression system
• Large fuel tank and superior fuel efficiency for less downtime
• EPA certified

Specifications:

• Product Dimensions
• Length in Operating Position: 63.0 – 68.5 inches (both models)
• Length in Storage Position: 41 inches (both models)
• Tracking Width: 21.2 inches (both models)
• Width: 23.25 inches (both models)
• Height in Operating Position: 32.75 inches (low) / 43.5 inches (high)
• Height in Storage Position: 22 inches (both models)
• Weight (without bagger): 132 lb (SFC-21-5CV), 138 lb (SFC-21-7CV)
• Weight (with bagger): 137 lb (SFC-21-5CV), 143 lb (SFC-21-7CV)
• General Specifications
• General Type: Heavy-duty industrial/commercial (both models)
• Brand: Kohler® Command PRO® (both models)
• Model: CV173 (SFC-21-5CV), CV224 (SFC-21-7CV)
• Horsepower: 5HP @ 3300 RPM (SFC-21-5CV), 7HP @ 3300 RPM (SFC-21-7CV)
• Engine Type: 4-cycle gas, OHV, air-cooled, single-cylinder, vertical shaft (both models)
• Displacement: 173 cc (SFC-21-5CV), 224 cc (SFC-21-7CV)
• Cylinder: One with cast-iron cylinder bore (both models)
• Governor: Mechanical governor with variable speed control set at 3300 rpm, idle set at 1500 rpm (both models)
• Air Cleaner: Quad-Clean™ four-stage, cyclonic air filter (both models)
• Exhaust: Side discharge muffler with guard (SFC-21-5CV), Front discharge muffler with guard (SFC-21-7CV)
• Oil Pump Group: Steel oil pump; Full pressure lubrication with spin-on oil filter (both models)
• Starter/Electrical: Easy-Pull™ recoil start (both models)
• 50-State Compliant: Yes (both models)
• Engine Deck & Fuel Tank
• Engine Deck Thickness: 14 gauge (both models)
• Fuel Tank Capacity: 0.37 gallon (1.4 liters) plastic tank (SFC-21-5CV), 1 gallon (3.785 liters) plastic tank (SFC-21-7CV)
• Wheels & Tires
• Drive Tires: 10.5 x 3 (both models)
• Front Tires: 9 x 2.25 (both models)
• Handlebars & Drive System
• Handle Bars: 1" diameter, thick wall tubing, 3-position adjustable (both models)
• Transmission: GT MG 512 transmission, 3-speed (both models)
• Steering/Travel Control: Variable drive control bar and 3-speed selector lever on handlebar (both models)
• Transmission Output Shaft: 0.50" diameter (both models)
• Safety & Forward Speed
• Safety Group: Handle actuated operator presence system (both models)
• Forward Speed: Up to 4.25 mph (both models)
• Cutter Deck
• Cutter Deck Type: High-vacuum, high-capacity design (both models)
• Deck Construction: 14 gauge deck with 14-gauge replaceable guards for strength and longevity. Deep draw stamped (both models)
• True Cutting Width: 21 inches (53.34 cm) (both models)
• Cutting Height Adjustment: 1.5" to 4.5" in 0.5" increments (both models)
• Cutter Blade: 0.1345 in. thick, milled edge, wear-resistant (both models)
• Blade Engagement: Blade control bar controlled Blade Brake Clutch (BBC), connected to cutter blade (both models)
• Discharge Opening: Rear-discharge with extra wide discharge opening (both models)
• Clutch Type: Heavy-duty Blade Brake Clutch (BBC) (both models)
• Optional Items/Attachments
• Mulching Plug: Included (both models)
• Fabric Grass Catcher: Included; 2.2 bushels (2.74 cu. ft.) (both models)
• Side-Discharge Adapter: Available accessory (both models)

Description:

Welded and fabricated using military-grade steel for years of dependable performance, the SFC-30 Finish Cut Walk-Behind Mower is no pushover. Packing big productivity and versatility into a compact form, this commercial-grade machine delivers a beautiful, professional quality-of-cut, helping you put the finishing touches on the job or at home.

FRONT SWIVEL CASTER WHEELS

Front swivel caster wheel model offers increased ease of manueverability in highly landscaped areas. Swivel wheel accessory also available to convert fixed wheel models.

Specification:

GENERAL

• Total Fuel Capacity: 1 gallon (0.37 gallon capacity for California models)
• Rear Tires: 10.5″ x 3″ rubber tire w/ glass-filled polypropylene wheel
• Front Tires: 9” x 2.25” rubber tire w/ glass-filled polypropylene wheel

DRIVE SYSTEM

• Drive System Type: GT MV 702 Transmission
• Forward Ground Speed: Up to 4 mph
• Parking Brake: Hand lever

DECK

• Cutting Widths: 30″
• Type: Extra-strong, fully fabricated and welded steel cutter deck. Offset blade, non-timed deck setup.
• Cutting Height: Adjustable from 1.5″ to 5″ in .25″ increments.
• Blade Type: Optimized for maximum performance whether discharging, mulching, or bagging
• Deck Lift: Hand lever. Single-point adjustment.
• Construction: 14-gauge, grade 100, Military Grade steel deck shell with 12-gauge spindle reinforcement plate. ¼” trim side reinforcement bar offers extra protection against impacts.
• Spindles: Aluminum housing with sealed ball bearings.
• Blade Engagement: Blade brake clutch allows operator to disengage cutter blades without shutting off the machine.
• Discharge, Mulch, Bag: Standard
• Bag Capacity: 2.5 Bushels

Product Dimensions

• Length – Transport (handles in upright transport position): 41″
• Length – Minimum (handles in highest operating position): 66″
• Length – Max (handles in lowest operating position): 73.5″
• Tracking Width: 28.75″
• Width (w/ discharge chute): 36.75″
• Width (w/ discharge block off plate): 31.5″
• Height – Lowest Operating: 36.75″
• Height – Max Operating: 45.25″
• Height – w/ Handle Bar in Storage Position: 57.5″
• Operating Weight – Bagging: 220 lbs.
• Operating Weight – Mulching: 214 lbs.
• Operating Weight – Discharging: 213 lbs.

Description:

The power of a tiger with the swiftness of a cat, the nimble Tiger Cat® II combines the best of both worlds. Making full use of its compact footprint and robust engine, this easily adjustable and extremely durable machine gets into, around and out of tight spaces quickly—putting you on the path toward increased profitability.

48", 52" OR 61" CUTTING WIDTH

The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge. This deck is equipped with Scag’s ultra-tough cast-iron spindles featuring tapered roller bearings and a top-mounted grease fitting with a relief valve to prevent over-greasing.

Product Dimensions

• 48″ Tiger Cat
• Length: 80″
• Width (chute down): 60.5″
• Width (chute in transport position): 49.75″
• Height (ROPS folded): 46.75″
• Height (ROPS up): 67.25″
• Weight: 1,175 lbs
• 52″ Tiger Cat
• Length: 80″
• Width (chute down): 64.5″
• Width (chute in transport position): 53.75″
• Height (ROPS folded): 46.75″
• Height (ROPS up): 67.25″
• Weight: 1,175-1,180 lbs
• 61″ Tiger Cat
• Length: 80″
• Width (chute down): 73.5″
• Width (chute in transport position): 62.75″
• Height (ROPS folded): 46.75″
• Height (ROPS up): 67.25″
• Weight: 1,257-1,277 lbs

GENERAL

• Total Fuel Capacity: 9.5 gallons
• Drive Tires:
• 24″ x 9.5″-12″ (48″ and 52″ models)
• 24″ x 12″-12″ (61″ model)
• Caster Tires: 13″ x 6.5″-6″, flat-free
• Seat: 4-point iso-mounted mid-back mounted on operator-suspension platform

DRIVE SYSTEM

• Drive System Type: Dual Pump and Motor
• Pumps: Hydro-Gear 12 cc
• Motors: Parker 14.5 ci
• Forward Ground Speed: 12 mph
• Reverse Ground Speed: 5 mph
• Parking Brake: Foot-operated pedal

DECK

• Cutting Widths: Available in 48″, 52″, and 61″
• Type: Velocity Plus™
• Cutting Height: Adjustable from 1″ to 5″ in .25″ increments
• Deck Lift: Adjustable foot-operated pedal
• Construction: Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles.
• Spindles: Cast-iron housing with tapered roller bearings.

Description:

The Scag Tiger Cat II is a zero-turn mower designed for professional landscapers who demand a machine that's both powerful and maneuverable. It combines the strength of a tiger with the nimbleness of a cat, allowing you to tackle tough jobs in tight spaces with unmatched efficiency.

Built for Endurance:

• Tri-Plate Deck Tops: The nearly half-inch thick steel deck construction (almost half an inch!) ensures exceptional durability, built to withstand heavy-duty use.
• Superior Cut Quality: The Velocity Plus™ deck with a special front baffle chamber and anti-scalp rollers delivers a clean, professional cut while preventing damage to your turf.
• Easy Maintenance: Features like replaceable wear pads and easy access points simplify keeping your mower in top condition.

Power and Control at Your Fingertips:

• Engine Options: Choose from a variety of engine options to match your power needs.
• Hydro-Gear Dual Pump and Motor Drive System: Delivers smooth operation and precise control for effortless maneuvering.
• Foot-operated Parking Brake: Provides convenient control when stopping or dismounting the mower.

Additional Highlights:

• Zero-Turn Design: Enables sharp turns around obstacles, maximizing your productivity.
• Adjustable Cutting Height: Allows you to customize the cut for different grass types and conditions. (1" to 5" in 0.25-inch increments)
• Comfortable Operator Platform: The mid-back seat mounted on an operator-suspension platform reduces fatigue during long working hours.
• The Scag Tiger Cat II is ideal for professional landscapers who need a powerful and agile zero-turn mower to handle demanding workloads. Its combination of durability, cutting performance, maneuverability, and operator comfort makes it a top choice for getting the job done efficiently.

Description:

It’s time for you to rise to the top of the food chain and tame turf with the Turf Tiger II™, a machine that’s tougher than any job you can throw at it. Engineered for superior durability, productivity and comfort, the Turf Tiger II gives you the edge over whatever nature throws at you while leaving you ready to take on the next challenge.

52", 61" OR 72" CUTTING WIDTH

The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge. This deck is equipped with Scag’s ultra-tough cast-iron spindles featuring tapered roller bearings and a top-mounted grease fitting with a relief valve to prevent over-greasing.

Product Dimensions:

• 52″ Turf Tiger Gas / Propane
• Length: 80.5″
• Width (chute down): 64.5″
• Width (chute in transport position): 53.75″
• Height (ROPS down): 46.5″
• Height (ROPS up): 68″
• Weight: 1,418 lbs (Gas) / 1,486 lbs (Propane)
• 61″ Turf Tiger Gas / Propane / Diesel
• Length: 85.5″ (Gas / Propane) / 88″ (Diesel)
• Width (chute down): 73.5″
• Width (chute in transport position): 62.75″
• Height (ROPS down): 46.5″ / 52.5″
• Height (ROPS up): 68″
• Weight: 1,496-1,538 lbs (Gas / Propane) / 1,606 lbs (Diesel) / 1,709 lbs (Diesel)
• 72″ Turf Tiger Gas / Diesel
• Length: 89.5″ (Gas) / 92″ (Diesel)
• Width (chute down): 83″
• Width (chute in transport position): 73.75″
• Height (ROPS down): 46.5″
• Height (ROPS up): 68″
• Weight: 1,556 lbs (Gas) / 1,739 lbs (Diesel)

GENERAL

• Total Fuel Capacity:
• 12 gallons (Gas/Diesel)
• 33.5 lb (LP)
• Drive Tires:
• 26″ x 12″-12″ (61″ and 72″)
• 26″ x 9.5″-12″ (52″)
• Caster Tires: 13″ x 6.5″-6″
• Seat: 4-point iso-mounted torsion-spring suspension seat

DRIVE SYSTEM

• Drive System Type: Dual Pump and Motor
• Pumps: Hydro-Gear: 16 cc
• Motors: Parker: 18 ci
• Forward Ground Speed:
• 12 mph (Gas/LP)
• 10 mph (Diesel)
• Reverse Ground Speed: 6 mph
• Parking Brake: Adjustable foot-operated pedal. AUSCO disc brakes.

DECK

• Cutting Widths: Available in 52″, 61″, and 72″
• Type: Velocity Plus™
• Cutting Height: Adjustable from 1.5″ to 6″ in .25″ increments
• Deck Lift: Adjustable foot-operated pedal
• Construction: Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles.
• Spindles: Cast-iron housing with tapered roller bearings.

Description:

It’s time for you to rise to the top of the food chain and tame turf with the Turf Tiger II™, a machine that’s tougher than any job you can throw at it. Engineered for superior durability, productivity and comfort, the Turf Tiger II gives you the edge over whatever nature throws at you while leaving you ready to take on the next challenge.

52", 61" OR 72" CUTTING WIDTH

The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge. This deck is equipped with Scag’s ultra-tough cast-iron spindles featuring tapered roller bearings and a top-mounted grease fitting with a relief valve to prevent over-greasing.

Product Dimensions:

• 52″ Turf Tiger Gas / Propane
• Length: 80.5″
• Width (chute down): 64.5″
• Width (chute in transport position): 53.75″
• Height (ROPS down): 46.5″ / 52.5″
• Height (ROPS up): 68″
• Weight: 1,418 lbs (Gas) / 1,486 lbs (Propane)
• 61″ Turf Tiger Gas / Propane / Diesel
• Length: 85.5″ (Gas / Propane) / 85.5″ (Gas / Propane) / 88″ (Diesel)
• Width (chute down): 73.5″
• Width (chute in transport position): 62.75″
• Height (ROPS down): 46.5″ / 52.5″ / 46.5″
• Height (ROPS up): 68″
• Weight: 1,496-1,538 lbs (Gas / Propane) / 1,606 lbs (Gas / Propane) / 1,709 lbs (Diesel)
• 72″ Turf Tiger Gas / Diesel
• Length: 89.5″ (Gas) / 92″ (Diesel)
• Width (chute down): 83″
• Width (chute in transport position): 73.75″
• Height (ROPS down): 46.5″
• Height (ROPS up): 68″
• Weight: 1,556 lbs (Gas) / 1,739 lbs (Diesel)

GENERAL

• Total Fuel Capacity:
• 12 gallons (Gas/Diesel)
• 33.5 lb (LP)
• Drive Tires:
• 26″ x 12″-12″ (61″ and 72″)
• 26″ x 9.5″-12″ (52″)
• Caster Tires: 13″ x 6.5″-6″
• Seat: 4-point iso-mounted torsion-spring suspension seat

DRIVE SYSTEM

• Drive System Type: Dual Pump and Motor
• Pumps: Hydro-Gear: 16 cc
• Motors: Parker: 18 ci
• Forward Ground Speed:
• 12 mph (Gas/LP)
• 10 mph (Diesel)
• Reverse Ground Speed: 6 mph
• Parking Brake: Adjustable foot-operated pedal. AUSCO disc brakes.

DECK

• Cutting Widths: Available in 52″, 61″, and 72″
• Type: Velocity Plus™
• Cutting Height: Adjustable from 1.5″ to 6″ in .25″ increments
• Deck Lift: Adjustable foot-operated pedal
• Construction: Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles.
• Spindles: Cast-iron housing with tapered roller bearings

Description:

Featuring a comfortable operator platform with first-class suspension that minimizes fatigue, the V-Ride II™ delivers a natural, intuitive and smooth riding position the entire day. With unrivaled performance, stability and durability, this machine helps keep you in tip-top condition to get the job done day after day, year after year.

48", 52" OR 61" CUTTING WIDTH

The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge on 48″, 52″ and 61″ widths

Specification:

Model Description:

• Model: SVRII-61V-26CV-EFI
• Deck: 61" Velocity Plus™ Cutter Deck
• Engine: 26 HP Kohler® Command PRO® EFI (electronic fuel injection)

Product Dimensions:

• Length: 72.75 inches
• Tracking Width: 48 inches
• Width (Chute Down): 73.5 inches
• Width (Chute in Transport Position): 62.75 inches
• Height: 47.25 inches
• Weight: 1,127 - 1,173 lbs

General:

• Total Fuel Capacity:
• 5 gallons (32" model)
• 6.75 gallons (36" model)
• 8 gallons (48", 52", and 61" models)
• Drive Tires:
• 20" x 6.5"-10" (32" model)
• 20" x 8"-10" (36" model)
• 24" x 9.5"-12" (48" and 52" models)
• 24" x 12"-12" (61" model)
• Caster Tires:
• 11" x 4"-5" (32" and 36" models)
• 13" x 5"-6" (48" and 52" models)
• 13" x 6.5"-6" (61" model)
• Seat: Extra-large comfort cushion

Drive System:

• Drive System Type: Dual Pump and Motor
• Pumps:
• Hydro-Gear 10 cc (32" and 36" models)
• Hydro-Gear 12 cc (48", 52", and 61" models)
• Motors:
• Parker 12 ci (32" and 36" models)
• Parker 14 ci (48", 52", and 61" models)
• Forward Ground Speed:
• 8.5 mph (32" and 36" models)
• 10.5 mph (48", 52", and 61" models)
• Reverse Ground Speed: 5 mph
• Parking Brake: Hand lever

Deck:

• Cutting Widths: 32", 36", 48", 52", and 61"
• Type:
• Advantage (32" and 36" models)
• Velocity Plus™ (48", 52", and 61" models)
• Cutting Height: 1.5" to 4.5" in 0.25" increments
• Deck Lift: Hand lever
• Construction: Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2" of steel. Reinforcement plates at cutter deck spindles. 32" model features dual-plate.
• Spindles: Cast-iron housing with tapered roller bearings
• Blade Engagement:
• Ogura GT2.5 (150 ft lb) for 32", 36", 48", and 52" models
• Ogura GT3.5 (250 ft lb) for 61" model
• Adjustable Air-Gap: For extended life

Description:

48", 52" OR 61" CUTTING WIDTH

The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge on 48″, 52″ and 61″ widths. An Advantage Cutter Deck is featured on 32″ and 36″ widths.

Ogura PTO Clutch Brake

STRONG, ADJUSTABLE CLUTCH FOR LONG LIFE

Provides excellent starting and stopping power for the cutter deck and an adjustable air gap for long life.

Adjustable Operator Platform

EXPERIENCE AN UNMATCHED, ULTRA-COMFORTABLE RIDE

The spacious operator platform delivers a smooth ride and reduces operator fatigue. Adjustable suspension spring can be moved forward or backward, with, or without, the spacer plate installed to meet the operator’s comfort preference. Extra-large, extra-thick operator comfort cushion ensures comfortable operation, hour after hour.

Cutter-Deck Lift System

CONVENIENT, SPRING-ASSISTED LEVER

Cutter deck can be lifted and locked into transport position from the operator’s station. Cutting heights are easily set by placing the tethered pin at the desired height.

High-Strength Steel Frame

SOLID DESIGN FOR YEARS OF DEPENDABLE SERVICE

Heavy-duty, single-tube, steel main-frame construction delivers superior strength and ensures years of trouble-free service. The front caster-wheel weldments are replaceable.

Industrial-Grade Hydraulic System

SPEEDS UP TO 10.5 MPH

48″, 52″ and 61″ models: Dual Hydro-Gear pumps (12 cc) and Parker wheel motors (14 ci) deliver dependable power, with speeds up to 10.5 mph. Pump shock valves ensure reliability and long life. Cooling fans help maintain safe operating temperatures.

32″ and 36″ models: Dual Hydro-Gear pumps (10 cc) and Parker wheel motors (12 ci) deliver dependable power, with speeds up to 8.5 mph.

Ease of Maintenance

MORE UPTIME

Easy-to-remove covers, an unrestricted engine compartment, easy-to-reach grease Zerks and many more features make servicing the V-Ride™ II simple, so you can be in the shop less and on the job more.

Tiger Eye Advanced Monitoring System

KEEP A REAL-TIME "EYE" ON IMPORTANT SYSTEM FUNCTIONS

Depending on the mower model and engine selection, the Tiger Eye™ Advanced Monitoring System monitors a wide variety of systems in real-time, giving you valuable information in just a glance, right from the operator’s seat. (Tiger Eye not available on 32″ and 36″ V-Ride II models.)

Powerful and Efficient Engine Options

HUGE POWER, UP TO 40 HP

Choose from Briggs Vanguard and Kawasaki® powerplants; electronic fuel injection (EFI) options are available.

Specification

• Model Description
• SVRII-61V-37BV-EFI
• 61" Velocity Plus™ Cutter Deck, 37 HP Briggs Vanguard™ BIG BLOCK EFI - electronic fuel injection
• Product Dimensions
• Length: 72.75"
• Tracking Width: 48"
• Width (chute down): 73.5"
• Width (chute in transport position): 62.75"
• Height: 47.25"
• Weight: 1,127-1,173 lb
• General
• Total Fuel Capacity:
• 5 gallons (32" deck)
• 6.75 gallons (36" deck)
• 8 gallons (48", 52", and 61" decks)
• Drive Tires:
• 20" x 6.5"-10" (32" deck)
• 20" x 8"-10" (36" deck)
• 24" x 9.5"-12" (48" and 52" decks)
• 24" x 12"-12" (61" deck)
• Caster Tires:
• 11" x 4"-5" (32" and 36" decks)
• 13" x 5"-6" (48" and 52" decks)
• 13" x 6.5"-6" (61" deck)
• Seat: Extra-large comfort cushion
• Drive System
• Drive System Type: Dual Pump and Motor
• Pumps:
• Hydro-Gear 10 cc (32" and 36" decks)
• Hydro-Gear 12 cc (48", 52", and 61" decks)
• Motors:
• Parker 12 ci (32" and 36" decks)
• Parker 14 ci (48", 52", and 61" decks)
• Forward Ground Speed:
• 8.5 mph (32" and 36" decks)
• 10.5 mph (48", 52", and 61" decks)
• Reverse Ground Speed: 5 mph
• Parking Brake: Hand lever
• Deck
• Cutting Widths: 32", 36", 48", 52", and 61"
• Type:
• Advantage (32" and 36" decks)
• Velocity Plus™ (48", 52", and 61" decks)
• Cutting Height: 1.5" to 4.5" in 0.25" increments
• Deck Lift: Hand lever
• Construction:
• Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2" of steel.
• Reinforcement plates at cutter deck spindles.
• 32" model features dual-plate.
• Spindles: Cast-iron housing with tapered roller bearings.
• Blade Engagement:
• Ogura GT2.5 (150 ft lb) - (32", 36", 48", and 52" decks)
• Ogura GT3.5 (250 ft lb) - (61" deck)
• Adjustable air-gap for extended life.

Description:

48", 52" OR 61" CUTTING WIDTH

The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge on 48″, 52″ and 61″ widths. An Advantage Cutter Deck is featured on 32″ and 36″ widths.

Ogura PTO Clutch Brake

STRONG, ADJUSTABLE CLUTCH FOR LONG LIFE

Provides excellent starting and stopping power for the cutter deck and an adjustable air gap for long life.

Adjustable Operator Platform

EXPERIENCE AN UNMATCHED, ULTRA-COMFORTABLE RIDE

The spacious operator platform delivers a smooth ride and reduces operator fatigue. Adjustable suspension spring can be moved forward or backward, with, or without, the spacer plate installed to meet the operator’s comfort preference. Extra-large, extra-thick operator comfort cushion ensures comfortable operation, hour after hour.

Cutter-Deck Lift System

CONVENIENT, SPRING-ASSISTED LEVER

Cutter deck can be lifted and locked into transport position from the operator’s station. Cutting heights are easily set by placing the tethered pin at the desired height.

High-Strength Steel Frame

SOLID DESIGN FOR YEARS OF DEPENDABLE SERVICE

Heavy-duty, single-tube, steel main-frame construction delivers superior strength and ensures years of trouble-free service. The front caster-wheel weldments are replaceable.

Industrial-Grade Hydraulic System

SPEEDS UP TO 10.5 MPH

48″, 52″ and 61″ models: Dual Hydro-Gear pumps (12 cc) and Parker wheel motors (14 ci) deliver dependable power, with speeds up to 10.5 mph. Pump shock valves ensure reliability and long life. Cooling fans help maintain safe operating temperatures.

32″ and 36″ models: Dual Hydro-Gear pumps (10 cc) and Parker wheel motors (12 ci) deliver dependable power, with speeds up to 8.5 mph.

Ease of Maintenance

MORE UPTIME

Easy-to-remove covers, an unrestricted engine compartment, easy-to-reach grease Zerks and many more features make servicing the V-Ride™ II simple, so you can be in the shop less and on the job more.

Tiger Eye Advanced Monitoring System

KEEP A REAL-TIME "EYE" ON IMPORTANT SYSTEM FUNCTIONS

Depending on the mower model and engine selection, the Tiger Eye™ Advanced Monitoring System monitors a wide variety of systems in real-time, giving you valuable information in just a glance, right from the operator’s seat. (Tiger Eye not available on 32″ and 36″ V-Ride II models.)

Powerful and Efficient Engine Options

HUGE POWER, UP TO 40 HP

Choose from Briggs Vanguard and Kawasaki® powerplants; electronic fuel injection (EFI) options are available.

Specification:

Model Description

• SVRII-61V-38CV-EFI
• 61" Velocity Plus™ Cutter Deck, 38 HP Kohler® Command PRO® EFI – electronic fuel injection

Product Dimensions

• Length: 72.75"
• Tracking Width: 48"
• Width (chute down): 73.5"
• Width (chute in transport position): 62.75"
• Height: 47.25"
• Weight: 1,127-1,173 lb

General

• Total Fuel Capacity:
• 5 gallons (32" deck)
• 6.75 gallons (36" deck)
• 8 gallons (48", 52", and 61" decks)
• Drive Tires:
• 20" x 6.5"-10" (32" deck)
• 20" x 8"-10" (36" deck)
• 24" x 9.5"-12" (48" and 52" decks)
• 24" x 12"-12" (61" deck)
• Caster Tires:
• 11" x 4"-5" (32" and 36" decks)
• 13" x 5"-6" (48" and 52" decks)
• 13" x 6.5"-6" (61" deck)
• Seat: Extra-large comfort cushion

Drive System

• Drive System Type: Dual Pump and Motor
• Pumps:
• Hydro-Gear 10 cc (32" and 36" decks)
• Hydro-Gear 12 cc (48", 52", and 61" decks)
• Motors:
• Parker 12 ci (32" and 36" decks)
• Parker 14 ci (48", 52", and 61" decks)
• Forward Ground Speed:
• 8.5 mph (32" and 36" decks)
• 10.5 mph (48", 52", and 61" decks)
• Reverse Ground Speed: 5 mph
• Parking Brake: Hand lever

Deck

• Cutting Widths: 32", 36", 48", 52", and 61"
• Type:
• Advantage (32" and 36" decks)
• Velocity Plus™ (48", 52", and 61" decks)
• Cutting Height: 1.5" to 4.5" in 0.25" increments
• Deck Lift: Hand lever
• Construction:
• Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2" of steel.
• Reinforcement plates at cutter deck spindles.
• 32" model features dual-plate.
• Spindles: Cast-iron housing with tapered roller bearings.
• Blade Engagement:
• Ogura GT2.5 (150 ft lb) - (32", 36", 48", and 52" decks)
• Ogura GT3.5 (250 ft lb) - (61" deck)
• Adjustable air-gap for extended life.

Description:

Get more jobs done from dawn to dusk in more comfort than ever before with the SWZT, featuring ultra-comfortable, ergonomic controls that contour to your hands. Equipped with our legendary toughness and durability, it is packed with features that deliver incredible power, smooth operation, and a long lifespan.

Specifications:

• Length of cutter deck: 52 inches
• Engine type: Briggs & Stratton
• Engine power: 20 HP
• Engine start type: Electric start

Description:

Because every home deserves stripes, the Liberty® Z is designed and manufactured to deliver a top-of-the-line experience at a homeowner price point. A professionally-constructed mower, fit for your own lawn. The Liberty Z gives more people the chance to see why Scag® machines are Simply the Best.

STRONG, ADJUSTABLE CLUTCH FOR LONG LIFE

The Ogura GT1 PTO Clutch Brake provides excellent starting and stopping power for the cutter deck, 74 ft. lb. of holding strength, and an adjustable air gap for long life.

Liberty Z Model Specifications

Product Dimensions:

• 36″ Liberty Z:
• Length: 68.5″
• Width (Chute Down): 48.5″
• Width (Chute in Transport Position): 37″
• Height: 40″
• Weight: 555 lbs
• 42″ Liberty Z:
• Length: 68.5″
• Width (Chute Down): 54.5″
• Width (Chute in Transport Position): 43″
• Height: 41″
• Weight: 595 lbs
• 48″ Liberty Z:
• Length: 67.5″
• Width (Chute Down): 60.5″
• Width (Chute in Transport Position): 49″
• Height: 41″
• Weight: 612 lbs
• 52″ Liberty Z:
• Length: 67.5″
• Width (Chute Down): 64.5″
• Width (Chute in Transport Position): 53″
• Height: 41″
• Weight: 646 lbs
• 61″ Liberty Z:
• Length: 73.5″
• Width (Chute Down): 73.5″
• Width (Chute in Transport Position): 62″
• Height: 41″
• Weight: 695 lbs

General:

• Total Fuel Capacity:
• 3.5 gallons: (36″ and 42″ models)
• 5.5 gallons: (48″, 52″, and 61″ models)
• Drive Tires:
• 20″ x 8″-10″: (36″ model)
• 20″ x 10″-8″: (42″, 48″, and 52″ models)
• 20″ x 10″-10″: (61″ model)
• Caster Tires:
• 11″ x 4″-5″: (36″ and 42″ models)
• 11″ x 6″-5″: (48″, 52″, and 61″ models)
• Seat:
• 48″, 52″, and 61″ models: Padded with arm rests, adjustment forward and back (tools required)
• 36″ and 42″ models: Optional armrest kit available

Drive System:

• Drive System Type:
• 36″ and 42″ models: Hydro-Gear ZT-2800 Transaxle
• 48″ and 52″ models: Tuff Torq TZ450 Transaxle
• 61″ model: Hydro-Gear ZT3100 Transaxle or Tuff Torq TZ450 Transaxle
• Pumps: Internal Pump: 10 cc
• Motors: Internal Motor: 10 cc (Tuff Torq), 16 cc (Hydro-Gear)
• Forward Ground Speed: 7 mph
• Reverse Ground Speed: 5 mph
• Parking Brake: Hand lever

Deck:

• Cutting Widths: 36″, 42″, 48″, 52″, and 61″
• Type: Heavy-Duty Hero Cutter Deck
• Cutting Height: 1.5″ to 4.5″ in 0.25″ increments
• Deck Lift: Foot-operated pedal
• Construction: Dual-plate cutter deck constructed of 2 steel plates. Reinforcement plate at cutter deck spindles.
• Spindles: Aluminum housing with sealed ball bearings
• Blade Engagement:
• Ogura GT1 (74 ft lb): (36″, 42″, 48″, and 52″ models)
• Ogura GT2 (108 ft lb): (61″ model)
• Adjustable Air-Gap: For extended life

Let me know if you need any more details
