Description:

48", 52" OR 61" CUTTING WIDTH

The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge on 48″, 52″ and 61″ widths. An Advantage Cutter Deck is featured on 32″ and 36″ widths.

Ogura PTO Clutch Brake

STRONG, ADJUSTABLE CLUTCH FOR LONG LIFE

Provides excellent starting and stopping power for the cutter deck and an adjustable air gap for long life.

Adjustable Operator Platform

EXPERIENCE AN UNMATCHED, ULTRA-COMFORTABLE RIDE

The spacious operator platform delivers a smooth ride and reduces operator fatigue. Adjustable suspension spring can be moved forward or backward, with, or without, the spacer plate installed to meet the operator’s comfort preference. Extra-large, extra-thick operator comfort cushion ensures comfortable operation, hour after hour.

Cutter-Deck Lift System

CONVENIENT, SPRING-ASSISTED LEVER

Cutter deck can be lifted and locked into transport position from the operator’s station. Cutting heights are easily set by placing the tethered pin at the desired height.

High-Strength Steel Frame

SOLID DESIGN FOR YEARS OF DEPENDABLE SERVICE

Heavy-duty, single-tube, steel main-frame construction delivers superior strength and ensures years of trouble-free service. The front caster-wheel weldments are replaceable.

Industrial-Grade Hydraulic System

SPEEDS UP TO 10.5 MPH

48″, 52″ and 61″ models: Dual Hydro-Gear pumps (12 cc) and Parker wheel motors (14 ci) deliver dependable power, with speeds up to 10.5 mph. Pump shock valves ensure reliability and long life. Cooling fans help maintain safe operating temperatures.

32″ and 36″ models: Dual Hydro-Gear pumps (10 cc) and Parker wheel motors (12 ci) deliver dependable power, with speeds up to 8.5 mph.

Ease of Maintenance

MORE UPTIME

Easy-to-remove covers, an unrestricted engine compartment, easy-to-reach grease Zerks and many more features make servicing the V-Ride™ II simple, so you can be in the shop less and on the job more.

Tiger Eye Advanced Monitoring System

KEEP A REAL-TIME "EYE" ON IMPORTANT SYSTEM FUNCTIONS

Depending on the mower model and engine selection, the Tiger Eye™ Advanced Monitoring System monitors a wide variety of systems in real-time, giving you valuable information in just a glance, right from the operator’s seat. (Tiger Eye not available on 32″ and 36″ V-Ride II models.)

Powerful and Efficient Engine Options

HUGE POWER, UP TO 40 HP

Choose from Briggs Vanguard and Kawasaki® powerplants; electronic fuel injection (EFI) options are available.

Specification:

Model Description

• SVRII-61V-38CV-EFI
• 61" Velocity Plus™ Cutter Deck, 38 HP Kohler® Command PRO® EFI – electronic fuel injection

Product Dimensions

• Length: 72.75"
• Tracking Width: 48"
• Width (chute down): 73.5"
• Width (chute in transport position): 62.75"
• Height: 47.25"
• Weight: 1,127-1,173 lb

General

• Total Fuel Capacity:
• 5 gallons (32" deck)
• 6.75 gallons (36" deck)
• 8 gallons (48", 52", and 61" decks)
• Drive Tires:
• 20" x 6.5"-10" (32" deck)
• 20" x 8"-10" (36" deck)
• 24" x 9.5"-12" (48" and 52" decks)
• 24" x 12"-12" (61" deck)
• Caster Tires:
• 11" x 4"-5" (32" and 36" decks)
• 13" x 5"-6" (48" and 52" decks)
• 13" x 6.5"-6" (61" deck)
• Seat: Extra-large comfort cushion

Drive System

• Drive System Type: Dual Pump and Motor
• Pumps:
• Hydro-Gear 10 cc (32" and 36" decks)
• Hydro-Gear 12 cc (48", 52", and 61" decks)
• Motors:
• Parker 12 ci (32" and 36" decks)
• Parker 14 ci (48", 52", and 61" decks)
• Forward Ground Speed:
• 8.5 mph (32" and 36" decks)
• 10.5 mph (48", 52", and 61" decks)
• Reverse Ground Speed: 5 mph
• Parking Brake: Hand lever

Deck

• Cutting Widths: 32", 36", 48", 52", and 61"
• Type:
• Advantage (32" and 36" decks)
• Velocity Plus™ (48", 52", and 61" decks)
• Cutting Height: 1.5" to 4.5" in 0.25" increments
• Deck Lift: Hand lever
• Construction:
• Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2" of steel.
• Reinforcement plates at cutter deck spindles.
• 32" model features dual-plate.
• Spindles: Cast-iron housing with tapered roller bearings.
• Blade Engagement:
• Ogura GT2.5 (150 ft lb) - (32", 36", 48", and 52" decks)
• Ogura GT3.5 (250 ft lb) - (61" deck)
• Adjustable air-gap for extended life.
