Description:

The Model C23i incorporates years of development and testing to deliver an upgraded mowing experience. The mower is designed to be fast, quiet, simple, and easy to maintain while still providing the top-notch performance that you expect from a Walker Mower.

The C23i features sheet and tube laser-cut parts, extensive robotic welding, and modular assemblies, resulting in precise and repeatable components that offer long-lasting durability. With a 13.25” thru-shaft Grass Handling System™ (GHS) blower, Hydro-Gear transaxles, and a Kohler Command Pro EFI engine, the mower is built for efficiency, reliability, and low maintenance.

The C23i is the next generation of Fast, Easy, Beautiful Mowing, offering superior performance, durability, and ease of use.

Specifications:

• C23i Model:
• Engine: Kohler ECH730
• Fuel System: EFI
• Cooling System: Air
• Displacement: 747 cc (45.5 cu. in.)
• Max Power: 23 HP @ 3600 RPM
• Max Torque: 38.1 ft-lbs
• Fuel Capacity: 4.7 gal (17.8 liters)
• Grass Handling: Collection
• Seat: Comfort Seat
• Tires: 18 x 8.50-10 Turf Tire
• Weight: 780 lbs (354 kg) (Tractor Only) / 999 lbs (453 kg) (With M48 Deck)
• Dimensions:
• Height: 50 in (127 cm)
• Width: 49.25 in (125 cm)
• Length: 96.25 in (244.5 cm)

C52R The productive 52-inch "R" deck is the largest collection deck in the Walker line. Operators can expect a beautiful, even cut in large areas along with excellent collection results. Standard with cast iron gearboxes. Type: Collection Part: DC52R-2 (Heavy Duty) Cutting Width: 52 in (132 cm) Blades: 2 Ideal Application: Widest grass collection deck ideal for wide area mowing

Five implements mount interchangeably on the Walker Mower using the quick-change hitch system. The Implement Hitch replaces the mower deck and installs on the tractor in less than a minute. Implements then slide onto the hitch and lock in place with the flip of a lever for true “quick change” capability. The hitch assembly includes operator footrests and an electric power lift. A switch raises and lowers implements and is quadrant mounted on the Forward Speed Control lever for convenient operation.

Description:

The DS42R Walker deck is side discharge and belt driven. Designed specifically for the Walker Model R

Specification:

• Type: Side Discharge
• Part Number: DS42R
• Cutting Width: 42 in (107 cm)
• Blades: 2
• Ideal Application: For Model R only, side discharge improves bystander safety and operator cleanliness
• Compatibility: Model R21

Description:

This higher horsepower, new generation version of the Model B adds a Kohler 26.5 HP, EFI engine and includes a redesigned unitized chassis and front body. The new clamshell body makes drivetrain component access easier, and the Ogura electric clutch with Soft Start adds convenience and durability for the operator.

An oversized Donaldson 5 inch air filter is fitted with a turbine style pre-cleaner and restriction gauge to reduce maintenance intervals while providing a robust filtration system. A new rear axle design improves rough condition handling, coupled with Walker’s Comfort Seat and optional 20” drive tires, make the B27i a comfortable machine that is powerful, efficient, and ready for larger decks and difficult conditions.

With numerous deck sizes and styles, optional LED Lights, Suspension Seat, Big Tire Kit, and Utility Dump Bed, the Model B is customizable to meet the needs of the most demanding customers. Contact your local dealer to request a demo today.

Specifications:

• Manufacturer: Kohler
• Model: ECH749
• Fuel System: EFI (Electronic Fuel Injection)
• Cooling System: Air
• Displacement: 747 cc (45.6 cu. in.)
• Max Power: 26.5 HP @ 3600 RPM
• Max Torque: 40 ft-lbs
• Fuel Capacity: 4.7 gal (17.8 liters)

Comfort & Features:

• Seat: Comfort Seat
• Tires: 18 x 8.5-10 (Pneumatic 4-Ply Low-Profile)

Weight:

• Weight (Tractor Only): 606 lbs (275 kg)
• Weight (Tractor with M48 Deck): 812 lbs (385 kg)

Dimensions:

• Height: 39.5 in (100 cm)
• Width: 49 in (125 cm)
• Length: 90.75 in (230 cm)

The 48-inch "R" collection deck is preferred for cutting in thinner grass and provides a smooth, even cut over a variety of cutting conditions. Standard with cast iron gearboxes.

SPECIFICATIONS

Type: Collection Part: DC48R-2 (Heavy Duty) Cutting Width: 48 in. (122 cm) Blades: 2 Ideal Application: Wide area mowing with reverse rotation for exceptional cut quality Width 48 in. (122 cm)

Description:

A powerful air-cooled engine with EFI technology delivers a responsive, fuel efficient performance. This mower provides powerful acceleration and throttle response. Built-in diagnostics and service light on the instrument panel simplify troubleshooting.

Description:

The R21 is the ideal machine for residential properties. Featuring a powerful 21 HP Kohler KT620 with Smart-Choke technology, this machine is a premium Walker Mower priced for residential owners. Tilt-open seat and tilt-up deck are designed for easy maintenance access.

Specifications:

• Engine
• Manufacturer: Kohler
• Model: KT620
• Displacement: 660 cc (40.3 cu. in.)
• Maximum Power: 21 HP @ 3600 RPM
• Governed RPM: 3600
• Maximum Torque: 35.9 ft-lbs
• Cooling System: Air
• Fuel Type: Gasoline (Unleaded, min. 87 octane)
• Fuel Capacity: 3 gal (11.36 liters)
• Electrical:
• Battery: 12V, 300 CCA
• Charging System: Flywheel Alternator
• Charging Output: 18 Amp DC (Regulated)
• Transmission:
• Manufacturer/Model: Dual Independent Hydro-Gear ZT-2200 Integrated Transaxles
• Steering: Hand Lever Control, Individual Wheel
• Forward Speed Control: Precision Friction Lock Lever, Cruise Control, with Neutral-Park Position
• Parking Brake: Mechanical Cog Lock for each Transaxle (Single Lever Control)
• Forward Speed: 0-6 MPH (0-10 km/h)
• Neutral: Transaxle Release by Manual Dump Valve
• Blade Drive:
• PTO Shaft: Single Belt
• Blade Drive Clutch and Brake: Electric Clutch (Stops Blades within 5 seconds of disengagement)
• Grass Handling:
• Grass Catcher Capacity (Optional Accelerator® Grass Catcher): 31 Gal / 3.3 Bu / 116 L
• Deck:
• Recommended Cut Width:
• Side Discharge: 42 to 48 in. (107 to 122 cm)
• Mulch: 42 to 48 in. (107 to 122 cm)
• Cutting Height: 1.5 to 4 in (4 to 10 cm)
• Deck Suspension: Independent Torsion-Flex Frame with Caster Wheels and Counterweight Springs
• Tires:
• Drive Tires: 18 x 8.50-10 (Pneumatic 4-Ply, Low Profile)
• Tailwheel: 13 x 6.50-6 (Pneumatic 4-Ply)
• Deck Caster: 8 x 3.00-4 (Semi-Pneumatic)
• Size & Weight:
• Length:
• Tractor with S48 Deck: 96 in (244 cm)
• Tractor with Deck Tilted: 74 in (188 cm)
• Tractor Wheelbase: 39 in (99 cm)
• Width:
• Tractor Only (Outside Tire): 39 in (99 cm)
• Tractor with S48 Deck: 49 in (124.5 cm)
• Height:
• Tractor: 42 in (107 cm)
• Weight:
• Tractor Only: 404 lbs (183 kg)
• Tractor with S48 Deck: (Incomplete data)
